Name: Beige / No Rhino Shelter | 22’W X 24’L X 12’H Portable Livestock Shelter (Animal Run-In) Round Style
SKU: LV222412HTN
Price: 2999.0 USD
Availability: InStock

The Rhino Shelters House-style Run-In shelter is designed to keep animals safe without sacrificing ventilation. The house-style roof prevents waterlogging and snow accumulation. Building a rhino shelter requires very little labor and equipment. The frame of the shed is constructed without the need for drilling or cutting.

The fabric of the main cover is CPAI-84 rated and composed of fire-resistant, UV-resistant poly with heat-welded seams and a woven backing. Between the outer and inner layers is a special layer called Inner Black Scrim. This layer has a coating that prevents sunlight from penetrating the substance.

Please Note: End Panels Are Not Included With Livestock Shelters & Sold Separately.

Included

Ten ounces. Cover for UV Treatment
14-piece cable earth anchor set
2-3/8-inch frame made of galvanized steel
Livestock shelters do not have end panels.

Unique Features

For maximum strength and longevity, all steel frame components have a heavy-duty galvanized finish.
Completely Pre-Drilled and Simple Bolt Assembly
Support for Wind Braces on all four corners
CPAI-84 Polyethylene Fabric Backed Cover, 10 oz.
End caps for protective plastic tubes with all open ends
Hardware Kit with Standard Thread Plating, Retaining Nuts, and Protective SS Washers
Fast Assembly Wrench
Robust Poly Rope for Main Cover Tie Down
Heavy Duty Grommets on Cover
Average Install time – 2 hours
Shipping Weight 789 lbs. shipped in Six (6) boxes Shipped via Motor Freight

Pipe Size

Click here Fabric Details

Click here for Steel Tubing Details

Standard Specifications

Product Size 22′ Width x 24′ Length x 12′ Height
Arches Seven (7) on 48″ spacing: 2-3/8″ galvanized frame members
Available Colors Forest Green, Gray and Tan
Interior Color White
Anchors Fourteen (14) 36″ Anchors with U-Bolts & 36″ Drive Rod
Shipping Method Shipped via Motor Freight Only

Box Dimensions Box 1: 60″ Long x 15″ Wide x 5″ High
Box 2: 88″ Long x 11″ Wide x 5″ High
Box 3: 50″ Long x 18″ Wide x 10″ High
Box 4: 65″ Long x 26″ Wide x 9″ High
Box 5: 60″ Long x 15″ Wide x 5″ High
Box 6: 67″ Long x 23″ Wide x 9″ High
Main Cover Fire Retardant Standard Main Cover meets CPAI -84 Section 5
UV Protected 24 mm, fabric-backed polyethylene, 10 oz weight
Shipping Weight 789 lbs. shipped in six (6) boxes
SKU LV222412HGN, LV222412HGY, LV222412HTN

Product Documentation

Manual 22W x 24L x 12H House

Rhino Shelter | 22’W X 24’L X 12’H Portable Livestock Shelter (Animal Run-In) Round Style
