EG4 12,000XP Off-Grid Inverter V2 48V Split Phase | 24kW PV Input 12kW Power Output

Authorized EG4 Dealer | Full Vendor Warranty Included

Customers rate us 4.6/5 based on 413 reviews.
$1,898.99
$3,999.00
$1,898.99
Save $2,100.01
🔒 Secret Discount on ALL EG4 products – ADD TO CART to reveal
Hurry! Only a few left in stock
Order in the next h min to get this to you between and

Need Help? Talk to our experts today!

Live Chat:
Bottom Right Text or Call us:
513-743-2829
🚚
Shipping & Delivery Time Shipping timeline above is an estimate. Please live chat for precise ETAs and shipping costs.
🛡️
30-Day Return Guarantee
Check Policy
💲
Price Match Available
🏷️
Sales Tax Free! (Except OH, FL, CA)
☀️ SUMMER DEALS ARE HERE – LOWEST PRICES GUARANTEED ☀️
Summer prices are here! Shop now to grab the lowest prices of the season before the sun sets.
EG4 12,000XP Off-Grid Inverter 48V Split Phase | 24kW PV Input 12kW Power Output - Green Vista Living

EG4

EG4 12,000XP Off-Grid Inverter V2 48V Split Phase | 24kW PV Input 12kW Power Output

$3,999.00 $1,898.99
EG4 12,000XP Off-Grid Inverter 48V Split Phase | 24kW PV Input 12kW Power Output - Green Vista Living
EG4 12,000XP Off-Grid Inverter 48V Split Phase | 24kW PV Input 12kW Power Output - Green Vista Living
EG4 12,000XP Off-Grid Inverter 48V Split Phase | 24kW PV Input 12kW Power Output - Green Vista Living
EG4 12,000XP Off-Grid Inverter 48V Split Phase | 24kW PV Input 12kW Power Output - Green Vista Living
EG4 12,000XP Off-Grid Inverter 48V Split Phase | 24kW PV Input 12kW Power Output - Green Vista Living

EG4

EG4 12,000XP Off-Grid Inverter V2 48V Split Phase | 24kW PV Input 12kW Power Output

$3,999.00 $1,898.99
  • Description

EG4 12,000XP Off-Grid Inverter V2| 48V Split Phase | 24kW PV Input | 12kW Power Output

Why this product is a must-have: The EG4 12,000XP Off-Grid Inverter V2 combines high power output, efficiency, and advanced communication features, making it an essential component for those looking to embrace off-grid living or enhance their energy independence.

Key Features

  • High Input Voltage (480VDC): Supports up to 24kW PV input, minimizing cabling needs and eliminating the requirement for a combiner box.
  • Dual MPPT Design: Maximizes solar energy utilization with optimal efficiency and stability under various sunlight conditions.
  • Plug-in Wi-Fi Capability: Allows remote monitoring and adjustment of settings via the EG4 app or Monitor system, enhancing convenience and control.
  • Closed-Loop Communication: Integrates seamlessly with EG4 48V batteries and select brands to improve system performance and safety.
  • Rapid Shut Down Compliance: Equipped with NEC 690.12-ready rapid shutdown capabilities for enhanced safety compliance.

Performance Highlights

  • 12kW Power Output: Consistent and robust power delivery, capable of managing heavy-duty appliances and equipment.
  • Surge Capacity up to 18kW: Provides extra power for demanding situations, lasting up to 5 seconds.
  • Expandable Power Options: Parallel up to six units for a total system capacity of 72kW, allowing for future scalability.
  • High Efficiency Rates: Achieves an impressive 99% MPPT efficiency, optimizing energy harvest and reducing loss.

Technical Specifications

  • AC Input: 120/240VAC | 50/60 Hz
  • Max Continuous Output: 12kW
  • Battery Compatibility: Supports Lead-Acid/Lithium with a minimum recommended capacity of 400Ah per inverter.
  • Operating Temperature: 32°F – 113°F (0°C – 45°C)
  • Protection Features: Includes PV Reverse Polarity, Over-Voltage, and Surge Protection.
  • Warranty: 5 years

Ideal Applications

  • Residential Off-Grid Living: Perfect for homeowners seeking independence from the grid.
  • Remote Worksites and Cabins: Ensures consistent power supply in isolated locations.
  • Commercial and Industrial Use: Reliable for demanding off-grid requirements.

What's Included:

  • 1 x 12000XP Off-Grid Inverter

  • 6 x Hex Head Wood Lag Screw

  • 6 x Expansion Bolts

  • Carboard Template

  • Wi-Fi Dongle

  • 1 x Parallel Communication Cable L=2m (Orange)

  • 1 x Battery Communication Cable L=2m (Grey)

  • 4 x Phillips Hex Head Bolt M5

  • Wall Mounting Bracket

  • 2 x Angle Bracket

  • 4 x Phillips Hex Head Bolt

  • 8 x Phillips Hex Head Bolt M6

  • User Manuals & Any Related Certifications

  • Fast, Reliable Shipping

  • Lifetime Customer Support

Product Specifications:

Specifications
Max. Units in Parallel 6
Product Dimensions (HxWxD) 34.25×20.87×5.91 in. (870×530×150 mm)
Unit Weight 104.7 lbs. (47.5 kg)
Design Topology High Frequency - Transformerless
Relative Humidity 5 – 95% (non-condensing)
Operating Altitude <6561 ft. (<2000 m)
Operating Ambient Temperature Range 32°F – 113°F (0°C – 45°C) @ Full Load
Storage Ambient Temperature Range 5°F – 140°F (-15°C – 60°C)
Noise Emission (Typical) <60 dB
Cooling Method Fan
Communication Interface RS485/CAN/Wi-Fi
Standard Warranty 5-year standard warranty
Ingress Protection Rating IP20
Safety Features PV Reverse Polarity Protection, Surge Protection Device, Output Over-Voltage Protection, Output Over-Voltage Protection Varistor
Standards and Certifications UL1741

Why Choose the EG4 12000XP? With its high output, advanced safety features, and remote management capabilities, the EG4 12,000XP off-grid inverter stands as a top-tier solution for all your off-grid energy needs, providing reliability and scalability for both residential and commercial applications.
