Pointguard Energy Load Hub2

SKU: 11110003
Manufacturer: Pointguard Energy

Intelligent Home Energy Management and Backup Control

The Load Hub2 is an advanced home energy management and load-control solution designed to provide greater control over how electricity is distributed throughout a residential energy system. It can connect up to two compatible Pointguard Home systems while allowing homeowners to select, prioritize, monitor, and control important household loads.

With support for both whole-home and partial-home backup, Load Hub2 helps manage critical and high-power equipment during normal operation and power outages. It is designed for applications involving solar energy, battery storage, the utility grid, and backup generators.

Key Features

• Connects up to two Pointguard Home systems

• Six double-pole controllable load positions

• Supports up to 12 single-pole loads

• Designed for high-power loads such as central air conditioners and pool pumps

• Dedicated support for generator connections

• Supports heat pumps and other controllable loads

• 0 ms load-side disruption when switching to backup mode

• Supports whole-home or partial-home backup

• Enables uninterrupted power delivery through PV, energy storage, utility grid, and generator sources

• Allows users to select and prioritize which loads receive backup power

• Provides intelligent monitoring and control of home energy usage

Flexible Load Management

Load Hub2 gives homeowners greater flexibility when deciding which appliances and electrical circuits should remain operational during an outage.

The system provides six double-pole controllable load positions, which can also accommodate up to twelve single-pole loads. This makes it suitable for managing major electrical equipment such as:

• Central air conditioning systems

• Pool pumps

• Heat pumps

• Other high-power household equipment

• Backup generators

Users can prioritize selected loads according to their energy requirements and available backup capacity.

Whole-Home and Partial-Home Backup

Load Hub2 supports both whole-home and partial-home backup configurations. Depending on the system design, homeowners can provide backup power to an entire electrical panel or prioritize specific circuits and appliances.

This allows the energy system to be configured around the home's individual power requirements while helping optimize the available battery and solar capacity.

Seamless Backup Switching

One of the key features of Load Hub2 is its 0 ms load-side disruption when switching to backup mode.

When properly integrated with a compatible energy storage system, the transition between available power sources is designed to maintain continuous power to connected loads without an interruption noticeable at the load side.

Multiple Energy Sources

Load Hub2 is designed to coordinate power distribution across multiple energy sources, including:

• Solar PV

• Energy storage systems

• Utility grid

• Backup generators

This enables a flexible home energy architecture that can continue supplying prioritized loads when the utility grid is unavailable.

Electrical Specifications

The system is designed to integrate with compatible Pointguard energy management and storage equipment.

Installation and System Integration

Load Hub2 functions as part of a complete residential energy management system rather than as a standalone energy storage device. It is intended to work with compatible controllers, battery systems, solar generation, grid power, and generator equipment.

Its load-management architecture allows installers to configure electrical circuits according to the homeowner's backup priorities and system capacity.

Shipping Information

Single Unit:

• Quantity: 1 piece

• Package dimensions: 24 × 33 × 10 in

• Shipping weight: 64 lbs

Pallet:

• 8 boxes / 8 pieces

• Pallet dimensions: 34 × 48 × 43 in

• Shipping weight: 535 lbs

Ideal Applications

Load Hub2 is well suited for:

• Residential solar-plus-storage systems

• Whole-home backup power

• Partial-home backup systems

• Homes with high-power electrical loads

• Central air conditioning systems

• Pool equipment

• Heat pumps

• Generator-integrated energy systems

• Homes requiring intelligent load prioritization

• Solar and battery energy management installations

Product Benefits

Intelligent Load Control

Choose which household loads receive priority and manage energy consumption more effectively.

Seamless Backup

The system provides 0 ms load-side disruption during the transition to backup operation when installed as part of a compatible system.

Flexible Configuration

Support for both whole-home and partial-home backup allows the system to be configured for different residential power requirements.

Multi-Source Energy Management

Coordinate power from solar PV, batteries, the utility grid, and a generator within one integrated energy architecture.

High-Power Load Support

Designed to manage demanding electrical loads, including central HVAC systems, pool pumps, and heat pumps.

Important Compatibility Note

Load Hub2 is a component of an integrated energy management system and should be installed and configured with compatible Pointguard equipment and according to applicable electrical requirements. Proper sizing and installation should be performed by a qualified electrical professional.

Product Summary

The Load Hub2 provides intelligent control over residential electrical loads while integrating backup power, solar generation, energy storage, utility power, and generator sources. With support for multiple controllable loads, two compatible energy-system connections, whole-home or partial-home backup, and seamless backup switching, it provides a flexible foundation for advanced residential energy management.
