NeoVolta All-in-One with 7.6kW Inverter plus 14.4kWh/48Vdc NV14

The NeoVolta NV14 is a fully integrated, floor-mounted hybrid ESS that combines a bidirectional inverter with a 14.4 kWh LFP battery. It supports 120/240 V split-phase and 208 V grids, accepts up to 10 kW STC PV (2× MPPT), and provides 7.68 kW continuous AC output with NEMA 3R outdoor protection.

All-in-One Design: Hybrid inverter + 14.4 kWh LFP battery with integrated protections and communication.

Flexible Solar Input: 2 MPPTs, 2 inputs each; 125–460 V MPPT range; up to 10 kW STC PV.

Reliable Backup Power: 7.68 kW nominal output, 8.45 kW (10 s) surge; generator-ready (to 7.5 kW when no AC-coupled PV).

Outdoor-Rated & Quiet: NEMA 3R enclosure, intelligent air cooling, <54 dB operation.

Special Technology

Energy Intelligence & Monitoring: Wi-Fi/Ethernet connectivity with Solarman app; integrated metering/controls.

Built-in Safety Suite: AFCI, anti-islanding, insulation & residual current monitoring, reverse-polarity, lightning protection.

Warranty

10-Year / 6,000-cycle limited warranty.

Best Uses

Whole-Home Backup & TOU Shifting: Seamless PV + storage operation with generator support.

Outdoor or Garage Installs: NEMA 3R, floor-mount system with included sub-panel and accessories.

Specifications Table

About NeoVolta:

NeoVolta specializes in advanced home energy storage systems designed for reliability, safety, and long life. Their lithium iron phosphate (LFP) batteries deliver high efficiency, robust cycle performance, and seamless backup power during outages. NeoVolta systems integrate with solar to maximize self-consumption and reduce dependence on the grid.

FAQs

Is the NV14 compatible with my solar panels?
Yes. The NV14 is compatible with a wide range of solar panels. Your installer will design the optimal panel configuration based on your system size, layout, and energy needs.

Do I need a battery to use the NV14?
That depends on the system design. The NV14 can operate without a battery in certain configurations. However, adding a compatible battery allows you to store excess solar energy for use at night or during power outages.

How do I monitor the performance of my NV14?
The NV14 typically connects to an online monitoring platform, often via Wi-Fi or Ethernet. This allows you to track energy production, system performance, and battery status (if installed) through a web portal or mobile app.

What happens if there is a power outage?
If the NV14 is installed with a compatible battery and backup configuration, it can provide power to selected loads during a grid outage. Without a battery or backup setup, the system will automatically shut down for safety when the grid goes offline.

How do I maintain the NV14?
The NV14 requires minimal maintenance. Periodic visual inspections, ensuring proper ventilation, and checking for system alerts are generally sufficient. Your installer may recommend routine system checks as part of ongoing maintenance.

What is the efficiency of the NV14?
The NV14 is designed for high efficiency operation. For exact efficiency ratings and performance data, refer to the official NV14 manufacturer datasheet.

What are the input and output voltage ranges?
Input and output voltage ranges depend on the specific model and regional configuration. Consult the official NV14 technical documentation for full electrical specifications, including voltage and current limits.

What communication protocols does the NV14 use?
The NV14 commonly supports Wi-Fi–based monitoring and may offer additional communication options depending on the model. Refer to the manufacturer’s documentation for detailed protocol support.
