Grundfos 15SQ07-180 Well Pump | 15 GPM | 3/4 HP | 180 Ft | 240 VAC

Grundfos 15SQ07-1809 - SQ Series 3" Submersible Well Pump (2W - 200-240V)

  • Ideal for use with 3" I.D. or larger boreholes

Rated 15 GPM @ 250' Head Lift

  • Please see documents for sizing / pump curve information

3/4 HP Permanent-Magnet (PM) Stainless Steel Motor (2-Wire - 200-240V)

  • Highly-efficient design with thermal overload protection for added safety
  • Fitted with a replaceable cable plug for ease of use

Soft Start Design

  • Allows for a low starting current with a smooth and steady acceleration
  • Low current draw helps reduce wear & provides ability to use smaller gauge wire

Dry-Running Protection

  • Helps extend pump life by preventing pump damage due to lack of water in well

Highly-Efficient Stainless Steel Pump

  • Polyamide reinforced hydraulic pump components for more efficient energy use

"Floating" Impellers w/ Tungsten Carbine/Ceramic Bearings

  • Allows for high wear resistance to sand which extends pump life

Top-Bearing Upthrust Protection

  • Provides added protection to motor/pump during start-up

Overvoltage & Undervoltage Protection

  • Prevents damage to the motor if voltage moves outside rated range

Overload Protection

  • Reduces Motor RPM or turns off power to motor to prevent damage to motor

Overtemperature Protection

  • Built-in temperature sensor ensures optimum operating conditions for the motor

2-Year Warranty

Product Specifications

Grundfos 15SQ07-180 Well Pump | 15 GPM | 3/4 HP | 180 Ft | 240 VAC Product Specifications

Part Number: 96160149

General Information
Product Category: Water Pump
Motor
Voltage: 240 Volt
Running Amps: 8.4
Wire: 2-Wire
Thermal Protection: Yes
Pump
Gallons Per Minute: 15 Gallons
Outlet Diameter: 1-1/4 Inch
Self Priming: Yes
Pump Head Material: Stainless Steel
Housing Material: Stainless Steel
Impeller Material: Composite
Total Head Lift: 300 Feet
Discharge Port Size: 1-1/4 Inch
Submersible: Yes
Series: SQE
Engine
Horsepower: 0.75 HP
Overview
Product Category: Water Pump
Weight: 13 Pounds
Consumer Warranty: 2 Years
Product Length: 33.6 Inches
Product Width: 2.9 Inches
Product Height: 2.9 Inches

Product Manual

GRUNDFOS SMARTFLO (Product brochure)

GRUNDFOS SQE (Product brochure)

GRUNDFOS SQ, Submersible Pumps (Product brochure)



GRUNDFOS SQ (Product brochure/Pocket Guide)

DCW Quick Selection guide for Pressure Boosting (Product brochure)

SQ, SQE (Installation and operating instructions)

SQ, SQE (I & O instructions)

SQ, SQE, CU 331, and SP (Data booklet)
