BigBattery | 48V ETHOS 5.12kWh Stackable Battery Module

Top Authorized Dealer | Manufacturer Warranty Included

$1,740.00
$2,180.00
$1,740.00
Save $440.00
(-20%)
Please hurry! Only 5 left in stock

Price Match

Free Shipping*

Free 30-Day Returns*

All orders are sales tax free!

Shipping timeline listed above is an estimate. Please call or message us for precise ETAs.

BigBattery | 48V ETHOS 5.12kWh Stackable Battery Module - Green Vista Living

Vendor: BigBattery

BigBattery | 48V ETHOS 5.12kWh Stackable Battery Module

$2,180.00 $1,740.00

Vendor: BigBattery

BigBattery | 48V ETHOS 5.12kWh Stackable Battery Module

$2,180.00 $1,740.00

Welcome to the forefront of energy storage innovation with the BigBattery 48V ETHOS systems. These 5.12kWh battery modules form the backbone of adaptable power solutions suitable for a wide range of applications, including grid-tied residences, solar installations, remote off-grid locations, and commercial establishments across the country. Featuring Tier 1 LiFePO4 cells, renowned for their safety and durability, and offering scalability up to 80kWh per Control Box, the ETHOS system sets a new standard for dependable energy storage solutions.

  • Scalable Power: 5.12kWh modules, expandable up to 80kWh per ETHOS Control Box.
  • Safety First: Tier 1 LiFePO4 cells and built-in fire-extinguishing modules ensure maximum safety.
  • Smart Monitoring: Advanced BMS technology provides real-time monitoring of voltage, current, and temperature.
  • Reliable Connectivity: UL-certified connectors ensure secure and reliable power connections.
  • Durable Design: IP65-rated casing protects against the elements for long-lasting reliability.
  • Versatile Applications: Ideal for emergency backup or as part of a solar energy system.

SKU: FETHS-48051-G1

KU: FETHS-48051-G1
GTIN-12 (U.P.C.): 850061252067
System Voltage: 48V
Nominal Voltage: 51.2V
Chemistry: LiFePO4
kWh Capacity: 5.12kWh
Ah Capacity: 100Ah
Charging Voltage Range: 55.6 - 57V
Max Charge Voltage: 57V
Operating Voltage Range: 48 – 57V
Suggested Low Voltage Cutoff: 48 – 50.8V
Cell Configuration: 16S
Max Continuous Discharge Current: 100A
Max Continuous Power: 5120W
Max Discharge Peak Current: 150A (Max 5 seconds)
Max Charge Current: 100A
Charge Temperature Range: 32°F - 113°F (0°C - 45°C)
Discharge Temperature Range: -4°F - 140°F (-20°C - 60°C)
Optimal Discharge Temperature Range: 59°F - 95°F (15°C - 35°C)
Storage Temperature Range (SoC >50%): -4°F - 113°F (-20°C - 45°C) (Max 6 months)
Depth: 6.7 in (170 mm)
Width: 26.5 in (674 mm)
Height: 16.5 in (419 mm)
Max Connections: Up to (16) parallel connections per control box
Protection Rating: IP65
Communications: CANBus / RS485
Certifications: UL9540a, UL1973, & UN38.3



Designed For:

  • 48V Applications
  • Residential Power Systems
  • Home Solar Systems
  • UL-Certified ESS
  • Cabins & Tiny Homes
  • Family Homes & Mansions
  • Off-Grid Homesteads
  • Emergency Power
  • Whole Home Backup
  • Lead Acid Replacement
  • Intense Heat & Cold

Manual: Download
