MRCOOL DIY® 5th Gen E Star 36,000 BTU Single Zone Mini Split Air Handler 230V (DIY-36-HP-WMAH-230D25-O)

Top Authorized Dealer | Manufacturer Warranty Included

$1,281.00
$1,389.00
$1,281.00
Save $108.00
(-8%)
Please hurry! Only 5 left in stock

Price Match

Free Shipping*

Free 30-Day Returns*

All orders are sales tax free!

Shipping timeline listed above is an estimate. Please live chat for precise ETAs.

MRCOOL DIY® 5th Gen E Star 36,000 BTU Single Zone Mini Split Air Handler 230V (DIY-36-HP-WMAH-230D25-O)

Vendor: GeoCool

MRCOOL DIY® 5th Gen E Star 36,000 BTU Single Zone Mini Split Air Handler 230V (DIY-36-HP-WMAH-230D25-O)

$1,389.00 $1,281.00

Vendor: GeoCool

MRCOOL DIY® 5th Gen E Star 36,000 BTU Single Zone Mini Split Air Handler 230V (DIY-36-HP-WMAH-230D25-O)

$1,389.00 $1,281.00

MRCOOL DIY® 5th Gen E Star 36,000 BTU Single Zone Mini Split Air Handler 230V (DIY-36-HP-WMAH-230D25-O)

The 5th Generation MRCOOL® DIY® 36K BTU Ductless Mini-Split Heat Pump is an efficient and versatile heating and cooling solution for spaces up to 1550 sq. ft. Designed for true do-it-yourself installation, it requires no special tools or professional help, making setup quick, straightforward, and cost-effective. A key feature of this system is the pre-charged 25-foot DIY® QuickConnect® line set, arriving to you already filled with R-454B refrigerant.

This eliminates the need for vacuuming, reducing both installation time and expense. The included DIYPRO® cable further simplifies setup by removing the need for electrical conduit while enhancing durability against outdoor elements and wildlife. You can easily control the system using the included wireless remote, the SmartHVAC app on Apple and Android devices, or voice commands through Amazon Alexa and Google Assistant. For enhanced comfort, the Follow Me function ensures even temperature distribution by adjusting airflow based on the remote’s location. Dry Mode helps maintain a pleasant indoor environment by reducing excess humidity. Built for longevity, the Gold Fin® Condenser resists corrosion, making it ideal for coastal areas.

This system is backed by a robust warranty package, including a limited lifetime warranty, a 7-year compressor warranty, and a 5-year parts warranty. Experience effortless installation, smart features, and reliable year-round comfort with MRCOOL® DIY®.

Features

  • NEEP ccASHP Listed
  • Intertek listed 5031495
  • Easy DIY installation
  • Future-proof your investment with the included DIYPro® cable, eliminating the need for electrical conduit.
  • Keep the included remote close by, and MRCOOL DIY®'s Follow Me® function will track the air temperature around you to ensure maximum comfort.
  • The MRCOOL® Smart HVAC Controller® Module and App fully support Google Assistant & Amazon Alexa out of the box.

Dimensions

11.1" D x 14.25" H x 49.57" W

Tonnage

3

Voltage (V)

208/230

Phase

1

Cycle

60

Max Fuse Breaker (A)

15

Min Circuit Ampacity (A)

3

Mount Type

Wall

Color

White

Max Coverage Area

1550 sqft

Decibel Rating Low (DBA)

27.5

Decibel Rating High (DBA)

55.5

Number of Speeds

5

Oscillation

Yes

Liquid Line Size

3/8

Suction Line Size

5/8

Filter Type

Reusable

Auxiliary Heater Included

No

Auxiliary Heater Available

No

Fan Only Option

Yes

Quiet Mode

Yes

Auto Cool

Yes

WIFI Compatibility

Yes

APP Compatibility

Yes

Works with IOS

Yes

Works with Android

Yes

Remote Control Included

Yes

UL Listed

Yes

ETL Listed

Yes

AHRI Certified

Yes

Registered Warranty

Extended Limited Lifetime*

Base Parts Warranty

5

Base Compressor Warranty

7

Has Batteries

Yes

Contains Electronics

Yes

Contains Chemicals

Yes

Contains Aerosol

Yes

Contains Compressed Gas

Yes

Proposition 65 Warning

Yes

Net Weight (Lbs)

48.72

Gross Depth (In)

18.74

Gross Height (In)

16.57

Gross Width (In)

53.94

Gross Weight (Lbs)

67.9

Brochure
Install Manual
Remote Manual
Warranty
Accessory Manual
